Name of the equipment: Ammonia Decomposition Equipment
1. Rated gas output: 20Nm3/h (25%N2,75%H2)
2. Gas purity: dew point≤-60°C, residual ammonia≤5PPM
3. Working temperature: 800~850°C
4. Rated power: 24kW (voltage: 440V, 50Hz)
5. Rated ammonia consumption: 8kg/h
6. Working pressure: ≤0.1MPa
7. Regeneration temperature of dryer: 250~300°C
8. Rated power of dryer: 3kW(one is working, the other is for regeneration or standby)
9. Power voltage: AC220V, 60Hz
Country / Region: Taiwan
