Hot Isostatic Pressing Sintering Furnace

The basic principle of hot isostatic pressing sintering furnace is that the material is placed in a high temperature and high pressure environment, and the effect of heat energy and mechanical pressure is used to make the grains of the material diffuse and combine with each other, and finally form a dense material. The sintering temperature of hot isostatic pressing sintering furnace is usually above 1500℃, and the pressure can reach more than 200MPa. Hot isostatic pressing sintering furnace is a kind of equipment for preparing high hardness, high density and high strength materials.

Hot isostatic pressing furnace is a kind of sintering furnace with high efficiency and high precision, which has the advantages that other processing methods can not compare, so it has a wide application prospect in the field of material preparation.

Hot isostatic pressing furnace has the following advantages:

1. Fast sintering speed: Hot isostatic pressing furnace can complete the sintering process in a short time due to the use of high temperature and high pressure environment, thus improving production efficiency.

2. Good sintering effect: In the hot isostatic furnace, the product can be subjected to uniform pressure in all directions, and the high temperature environment is also conducive to the densification and performance optimization of the material. Therefore, high quality products can be obtained from hot isostatic furnace.

3. High density of material: The high temperature and high pressure environment in the hot isostatic pressing furnace can reduce the pores inside the material and increase the density of the material, thereby improving the mechanical properties and corrosion resistance of the material.

4. Wide range of applications: Hot isostatic pressing furnace can be used to prepare various materials, including metals, ceramics, composite materials, etc., especially this furnace has important application value in the preparation of high-performance ceramic materials.

The hot isostatic pressing furnace is composed of isostatic pressing device, vacuum system, gas system (including gas source), heating system, cooling system, hydraulic system and electrical control system.

Hot isostatic pressing technology is an advanced material processing technology integrating high temperature and high pressure. It has the characteristics of high efficiency pressure, high temperature environment, sealing environment, high density, homogeneity, energy saving and environmental protection. Therefore, it has a wide range of application prospects in the field of material processing and is an ideal special equipment for manufacturing high-quality aircraft engine blades, aerospace rocket ablative throat liners, spacecraft high temperature fairing and other key components.
