Microwave Atmosphere Rotary Furnace

Application

Microwave atmosphere rotary furnace is a type of microwave rapid heating atmosphere continuous furnace. Can inflate with atmosphere, used for process lithium iron battery positive and negative electrode materials(lithium iron phosphate, lithium manganate, lithium cobalt oxides, ternary materials, graphite cathode material, binary battery materials, nickel and cobalt acid lithium, etc.), rare earth materials, catalyst(titanium silicalite molecular sieves, ZSM-5, etc.), magnetic materials powder, powder metallurgy powder, nonferrous metals powder and some other particle’s reaction, reduction, composition, etc..

Inquire Now Next Product

Overview

As a kind of advanced heating technology in the world currently, microwave heating makes use of microwave penetration and selective heating characteristics to heat the overall material inside the insulation layer directly and rapidly. Its heating rate is 10-100 times faster than that of the traditional furnace.

Technical Parameter

Model	Voltage	Rated power	Microwave rated power	Max. temperature	Working temperature	Temperature rising rate	Heating zone	Furnace dimension
Model	V	KW	KW	℃	℃	℃/min	mm	WHL（mm）
CE-RO1100C-M	380V	15	9	1100	900	≤100	Ø120*1000	27006501800
CE-RO1000C-L	380V	25	15	1000	900	≤100	Ø220*1500	320011001800
CE-AR1100C-M	380V	15	9	1100	900	≤100	Ø120*1000	27006501800

Features

1. Fast temperature rising rate with max. 100℃/min.

2. Good performance of homogeneity, the material appears dynamic condition stirring in the furnace.

3. Serialization turnover material, the forward speed of the material can be adjustment based on the inclination.

4. Good performance of leakproofness, can be used for variety of atmosphere test

5. 7 inch touch screen to make operation simple.

6. Insulation fibre lightweight structure to save energy and realize high efficiency.

7. Less microwave leakage (≤0.5mw/cm²) which is much less than national standard(≤5mw/cm²)
