Microwave Atmosphere Sintering Furnace

As a kind of advanced heating technology in the world currently, microwave heating makes use of microwave penetration and selective heating characteristics to heat the overall material inside the insulation layer directly and rapidly. Its heating rate is 10-100 times faster than that of the traditional furnace.

Application

Experimental and production of biomass, coal, plastics, rubber, organic waste, etc.

Inquire Now Next Product

Overview

Microwave atmosphere sintering furnace is a type of microwave rapid speed heating atmosphere inflation high temperature box style furnace. Apply to a variety of material sintering, raised efficiency experiment and products quality substantially.

Technical Parameter

Model	Voltage	Rated power	Microwave rated power	Max. temperature	Working temperature	Temperature rising rate	Heating zone	Furnace dimension
Model	V	KW	KW	℃	℃	℃/min	mm	WHL（mm）
CE-AT1600C-M	220V	5	3	1600	1550	≤100	160120100(2L)	9007501800
CE-AT1700C-M	220V	5	3	1600	1550	≤100	12012080(1.2L)	9007501800
CE-AT1750C-M	380V	5	3	1700	1650	≤100	10010080	9007501800

Features

1. Fast temperature rising rate with max. 100℃/min.

2. 7 inch touch screen to make operation simple.

3. Vacuumize, sintering with atmosphere protecting

4. Insulation fibre lightweight structure to save energy and realize high efficiency.

5. The dimension of equipment is small, occupation of land≤0.7m²

6. Less microwave leakage (≤0.01mw/cm²) which is much less than national standard(≤5mw/cm²)
